Standard Operational Data

Processing capacity: 0.1 m3/h to 7,300 m3/h

Working pressure: max. 4.0 MPaG

Working temperature: max. 180°C

Heat transfer area: 0.18 m2/unit to 3,400 m2/unit

Plate material: Stainless steel: 304, 316, 315J1, 317, Etc.

Titanium: TP270, TP270-Pd

High nickel alloy: C-276, C-22, B, G Nickel: NNCP, NLCP

Other: Domestic and international standard materials

Gasket materials: NBR, IIR, EPDM, FPM, Silicon, TCG (PTFE cushion gasket)

* The above data varies depending on the model, material, plate thickness, and operating specifications.
